उत्पाद विवरण:
|
| मशीनरी परीक्षण रिपोर्ट: | प्रदान किया | बाहरी पोत सामग्री: | कार्बन स्टील |
|---|---|---|---|
| ओसांक: | -65 ℃ | बाहरी पोत व्यास: | 2000 मिमी |
| नाइट्रोजन उत्पादन: | ≤250Nm3 / घंटा | उत्पादन दर: | 100 ~ 10000nm3/h |
| बिजली की खपत: | 0.5-1.5 किलोवाट/एनएम3 | वायु कंप्रेसर शक्ति: | 22-110KW |
| बिजली की आपूर्ति: | 380V/50 हर्ट्ज | जीवन काल: | +10 वर्ष |
| ऑक्सीजन उत्पादन: | ≤500Nm3/घंटा | प्रयोग: | ऑक्सीजन |
| आंतरिक सामग्री: | स्टेनलेस स्टील | परीक्षण दबाव: | 0.8MPA-1.6MPA |
| प्रमुखता देना: | 93%±2% Purity VPSA Oxygen Generator,600m2 VPSA Oxygen Generator,0.5-1.5 kW/Nm3 Power Consumption Oxygen Generator |
||
| Model | O₂ Flow (Nm³/h) | O₂ Purity (±2%) | O₂ Pressure (MPa) | Air Consumption (Nm³/h) | Adsorption Form |
|---|---|---|---|---|---|
| VPSA-3 | 3 | 93% | 0.2 | 0.6 | Normal Pressure Adsorption |
| VPSA-6 | 6 | 93% | 0.2 | 1.2 | Normal Pressure Adsorption |
| VPSA-10 | 10 | 93% | 0.2 | 2 | Normal Pressure Adsorption |
| VPSA-20 | 20 | 93% | 0.2 | 4 | Normal Pressure Adsorption |
| VPSA-30 | 30 | 93% | 0.2 | 6 | Vacuum Adsorption |
| VPSA-50 | 50 | 93% | 0.2 | 10 | Vacuum Adsorption |
| VPSA-80 | 80 | 93% | 0.2 | 16 | Vacuum Adsorption |
| VPSA-100 | 100 | 93% | 0.2 | 20 | Vacuum Adsorption |
| VPSA-150 | 150 | 93% | 0.2 | 30 | Vacuum Adsorption |
| VPSA-200 | 200 | 93% | 0.2 | 40 | Vacuum Adsorption |
| System Name | Content | Parameter |
|---|---|---|
| Vacuum pump sealing water | Flow | 3m³/Hr |
| Temperature | <32ºC | |
| Water quality (soft water) | <30mg/L (CaO), suspended matter: 5mg/L, pH value: 6~9 | |
| Pressure | >0.2Mpa sent to the water inlet of water equipment | |
| Vacuum pump cooling water | Flow | 4m³/Hr |
| Temperature | <32ºC | |
| Water quality (soft water) | <560mg/L (CaO), PH value: 6~9 | |
| Pressure | >0.3Mpa sent to the water inlet of water equipment | |
| Oxygen compressor cooling water | Flow | Air-cooled |
| Instrument air for butterfly valve | Quality | Dry, clean instrument air or inert gas |
| Flow | 180m³/Hr | |
| Dew point temperature | -40ºC | |
| Dust particle size | Not more than 0.3μm | |
| Pressure | 0.4~0.7Mpa sent to the air bag (sub-cylinder) | |
| Power requirements | Voltage | 380V |
| Installed capacity | 539KW sent to the equipment receiving cabinet | |
| Civil plant | The project is designed outdoors without the client providing a factory building. | |
| Equipment basis | Construction according to drawing requirements | |
