उत्पाद विवरण:
|
| Valve Type: | Cryogenic Valve | Inner Vessel Material: | 304 Stainless Steel |
|---|---|---|---|
| Inner Vessel Type: | Double Wall | Empty Weight: | Cylindrical |
| Pressure: | 0.8Mpa | Inner Material: | stainless steel |
| Max Working Pressure: | 2.16mpa | Pressure Range: | 1.5 bar to 30 bar |
| प्रमुखता देना: | 30,000 m³ LPG storage tank,cryogenic storage tank with valve |
||
| Attribute | Value |
|---|---|
| Valve Type | Cryogenic Valve |
| Inner Vessel Material | 304 Stainless Steel |
| Inner Vessel Type | Double Wall |
| Empty Weight | Cylindrical |
| Pressure | 0.8Mpa |
| Inner Material | Stainless Steel |
| Max Working Pressure | 2.16mpa |
| Pressure Range | 1.5 bar to 30 bar |
Liquefied petroleum gas storage tanks are available as compressed gas or liquefied gas storage tanks. These tanks can be categorized into:
| Model (m³) | Design Pressure (MPa) | Cylinder Size (mm) | Dimensions (mm) | Material | Net Weight (Kg) |
|---|---|---|---|---|---|
| 5 | 1.77MPa | DN1200*4000*10 | 1800*1800*6000 | Q345R | 3200kg |
| 10 | 1.77MPa | DN1200*4400*10 | 2000*2000*6000 | Q345R | 3500kg |
| 15 | 1.77MPa | DN1600*5250*12 | 2300*2000*7000 | Q345R | 5200kg |
| 20 | 1.77MPa | DN1800*5800*12 | 2500*2000*1000 | Q345R | 3800kg |
| 25 | 1.77MPa | DN2200*7100*12 | 2600*2200*1200 | Q345R | 7000kg |
| 30 | 1.77MPa | DN2000*5500*12 | 2450*2000*7500 | Q345R | 7500kg |
For more information about our LPG storage solutions, please email us at info@gneeheatex.com. Our team is ready to assist with your specific requirements.
